Get Device Pairing Code



Instruction

To pair your edge device, you will first need Allxon Agent installed on your device & get the device pairing code. Follow the steps to get the pairing code.

<Environment> At your edge device

 圖片3

💡 Note

haven't got Allxon Agent installed on your device?

20210527_isometric02-04

Install Allxon Agent in a minute by following Install Allxon Agent on Edge Device



One last thing before paring the device on Allxon is to get your device pairing code from the device. Depending on your environment, you can choose to obtain the pairing code using Graphical User Interface (GUI) or Command-Line Interface (CLI).



back to top

Using Graphical User Interface (GUI)

<Environment>

Allxon Agent on edge device with Graphical User Interface.

GUI

  1. Bring up Allxon Agent by pressing “Ctrl + Shift + B” on your device.


    <💡 Note > If your device does not have Allxon Agent Installed on it, please refer to Install Allxon Agent on Edge Device to complete the installation.


  2. Click “Get device pairing code” button on the right.


  3. A device pairing code will be shown upon click.

back to top

Using Command-Line Interface (CLI)

<Environment>

Allxon Agent on edge device with Command-Line Interface.

CLI

💡 Note

  1. If your device does not have Allxon Agent Installed on it, please refer to Install Allxon Agent on Edge Device
  2. The Command-Line Interface is only supported in the following architectures and operation systems
    • Linux on ARM for NVIDIA Jetson systems running on Ubuntu 18.04
    • Linux x86 (32-bit & 64-bit) devices running on Ubuntu 18.04 & onward
  1. If you are accessing your device with Command-Line Interface, you can get the device pairing code by entering the command below via terminal or SSH client.
    • Linux: Get Pairing Code Command via terminal or SSH client.

      dms-get-pairing-code
    • A device pairing code will be shown upon execution.
